I本设计所需图纸请联系 380752645加 Q时请说明是一柱香推荐II摘 要改革开放以来，伴随着社会主义市场经济改革的不断深化和科教事业的突飞猛进，印刷机械行业迎来了最好的发展时期八开胶印机产品最初进入政府机关、学校，目的是代替或部分代替蜡版油印设备在复印机复制水性版技术问世以后，八开胶印机更以它的快捷和质量赢得了用户的青睐而八开双色小胶印机中的输纸机构又是一个特别重要的组成部分，本文针对该部分的设计进行展开，围绕胶印机的设计手册和八开双色小胶印机的设计规范要求详细分析了八开双色小胶印机的工作机构和工作条件，对八开双色小胶印机的金属结构的设计计算校核以及对八开双色小胶印机的各种工作稳定性进行了验算本次小胶印机的设计主要涉及八开双色小胶印机的接纸装置、输纸装置、超越续纸、规矩以及控制上述各部分的凸轮等结构的设计接纸装置、输纸装置等主要是针对运行原理及小胶印机的特性给予设计、选取零件结构和型号规矩、续纸、凸轮及控制部分即针对结构的整体性能和稳定给予验算本次设计还涉及到输纸部分的传动，主要运用齿轮传动最后联系整个设计，贯穿、整理，使之成为一个完善的整体关键词：八开双色小胶印机 输纸部分 结构设计 稳定验算IIIABSTRACTSince reform and opening, along with the socialist market economic reforms deepen and the rapid progress of science, education, business, printing machinery industry ushered in the best period of development. Octavo offset products first entered the government offices, schools, designed to replace or partially replace the Laban mimeographed equipment. Water-based version of the photocopier copying technology came later, eight more open in order to offset its fast and quality to win customers. The opening eight-color offset press in the feeding of small organizations is a particularly important part of this paper, the design of the part of the launch, around the offset of the design manual and eight small two-color offset press to open the design specifications in detail Analysis of eight two-color small offset press to open the work organization and working conditions, a small eight-color offset press to open the metal structure design and calculation of check and the little eight-color offset press to open all the work was checking the stability of . The small offset press designed mainly to open eight-color offset press in the splicing of small devices, feeding devices, beyond the continued paper, the rules and control the structure of the various parts of the cam design. Splicing devices, feeding devices primarily for the operation principle and the characteristics of a small offset to the design, structure and models of selected components. Rules, adding paper, part of the cam and control structure for the overall performance and stability for checking. This design also involves feeding part of the drive, the main use of gears. Last contact throughout the design, through, sorting, making a perfect whole.Keywords: Octavo two small offset machin Paper part mechanism design stability calculationIV目 录第 1章 绪论 .................................................11.1 胶印机的概述 ......................................................11.2 胶印机的组成和分类 ...............................................21.2.1 胶印机的组成 ................................................21.2.2 胶印机的分类 ................................................21.3 胶印机的现状和发展前景 ............................................3第 2章 八开双色小胶印机输纸部分的设计内容及要求 ..............72.1 输纸部分设计内容 .................................................72.2 输纸部分设计参数及要求 ...........................................72.2.1 输纸部分设计参数如下表 ......................................72.2.2 输纸部分设计要求 ............................................7第 3章 接纸装置的设计 .......................................83.1 接纸装置的组成 ....................................................83.2 分离头的设计要求及主要组成零件设计 ................................83.2.1 分离头的工作要求 ............................................83.2.2 分离头的主要组成部件 ........................................83.3 输纸台升降机构 ...................................................113.4 凸轮轴和送纸辊 ...................................................123.4.1 挡纸块 .....................................................123.4.2 接纸滚轮 ...................................................13第 4章 输纸装置的设计 .......................................154.1 输纸装置的组成 ...................................................154.2 输纸装置各部零件设计要求及步骤 ...................................154.2.1 输纸板 .....................................................154.3 输纸辊 ...........................................................164.3.1 输纸辊的设计要求 ...........................................164.4 输纸线带 .........................................................174.4.1 输纸线带的取材 .............................................17V4.5 输纸框架 ........................................................174.6 压纸滚轮 .........................................................174.6.1 压纸毛刷滚轮 ...............................................184.7 压力球 ...........................................................184.8 毛刷 .............................................................184.9 压纸片 ...........................................................184.10 输纸部分传动设计 ................................................18第 5章 递纸部分的设计 .......................................205.1 递纸部分的形式和分类 .............................................205.2 递纸部分的选择和组成 .............................................205.2.1 带动超越辊转动的传动齿轮 ...................................215.2.2 递纸牙摆臂 .................................................215.2.3 递纸牙摆杆连杆机构 .........................................215.2.4 递纸凸轮 ...................................................215.2.5 拉力弹簧 ........。
