Steel structure 面积： area 结构形式： framework 坡度： slope 跨度： span 柱距： bay spacing 檐高： eave height 屋面板： roof system 墙面板： wall system 梁底净高 : clean height 屋面系统 : roof cladding 招标文件 : tender doc 建筑结构结构可靠度设计统一标准 : unified standard for designing of architecture construction reliablity 建筑结构荷载设计规范 : load design standard for architecture construction 建筑抗震设计规范 : anti-seismic design standard for architecture 钢结构设计规范 : steel structure design standard 冷弯薄壁型钢结构技术规范 : technical standard for cold bend and thick steel structure 门式钢架轻型房屋钢结构技术规范 : technical specification for steel structure of light weight building with gabled frames 钢结构焊接规程 : welding specification for steel structure 钢结构工程施工及验收规范 : checking standard for constructing and checking of steel structure 压型金属板设计施工规程 : design and construction specification for steel panel 荷载条件： load condition 屋面活荷载： live load on roof 屋面悬挂荷载： suspended load in roof 风荷载： wind load 雪荷载： snow load 抗震等级： seismic load 变形控制： deflect control 柱间支撑 X 撑： X bracing 主结构： primary structure 钢架梁柱、端墙柱 : frame beam, frame column, and end-wall column 钢材牌号为 Q345 或相当牌号，大型钢厂出品： Q345 or equivalent, from the major steel mill 表面处理：抛丸除锈 Sa2.5 级，环氧富锌漆，两底两面，总厚度为 125UM 。
表面喷涂防火 材料，防火等级为：柱 2 小时，梁 1.5 小时surface treatment: shot blasting to Sa2.5,zinc rich epoxy paint. 2primer paint and 2 finish paint .total dry film thickness 125um. Spraying fireproof painting on surface, for column 2hours and beam 1.5hours.次结构包括：屋面檩条、围梁、门窗开口加强等，工厂轧制成C型、Z型截面，工厂预冲孔Secondary structure included purlins, girts, roof opening and wall opening reinforcement, prepunched and rolled to C or Z section on factory machine.材质：热浸镀锌卷材， Q345 或相当牌号， 大型钢厂出品或进口 Material : hot-dipped galvanized steel coil, Q345 or equivalent, from the major domestic steel mills or imported.支撑系统：brae ing sys包括X型柱间支撑、屋面支撑、拉条及隅撑等。
采用圆钢、钢管或角钢等Bracing sys in eludes X brae ing betwee n colu mns, roof braci ng, tie rods and an gle braci ng. Round bars, steel tubes or an gle profiles are used.屋面系统：roof sys屋面外板：采用通过美国 FM认证打开色镀锌 SS360直立锁缝板，卷板为宝钢出品， 24Ga厚，正常使用寿命为 20 年Roof panel: FM certificated alum-zinc standing seam 360 roof panel.The raw material is alum-zinc alloy coated steel from Baosteel, 24Ga thickness. Warranty of coati ng is 20 years in no rmal use.屋面保温棉：采用欧文斯-科宁(Owens-corning)公司生产的结构用玻璃棉毡， 厚度为75mm 容重为 14K/M3 ,WR8 贴面o Roof insulation: fiber glass insulation blanket from Owens -corning, thick ness is 75mm, 14Kg/m3, WR8 facing.屋面采光板：单层，基本均匀布置，屋面面积的 2%roof skylight pan el: sin gle layered,2%area of roof, evenly allocated.过廊部分的屋面板：单层，无保温，材质同外墙面板。
Roof panel in corridor area: sin gle layered color plate without in sulati on, same panel with exterior wall pan el.墙面系统：wall sys墙面外板：采用通过美国FM认证的LSP板，卷板为宝钢出品，彩色镀铝锌板，PVDF涂层， 26Gamm厚正常使用情况下的寿命为 20年Exterior wall pan el: FM certificated sha nghai ABC ' long spa n panel (LSP). Raw material is alum-z inc steel from Baosteel with PVDF coat ing, 26Ga thick ness. warra nty period is 20 years in no rmal use.墙面保温棉：采用欧文斯-科宁)(Owens-corning )公司生产的结构用玻璃棉毡， 厚度为75mm ,容重为12Kg/m3,贴面为铝箔(aluminum foil)Wall in sulati on: fiberglass in sulati on bla nket from Owen s-cor ning, thick ness is 75mm,12Kg/m3, FSK facing.墙面内板：采用上海美建生产的 LSP3板，材料为宝钢出品，彩色镀锌板， PE涂层，28Ga厚。
In terior wall in sulati on : Shan gHai ABC ' LSP3 pan el. Raw material is galva ni zed steel from Baosteel with PE coat ing, 28Ga thick ness.雨棚：材质同外墙壁面板，单层，其中：卸货棚的 30m*10.75m(宽*长，下同)一个大雨棚为拉杆式雨棚；1m*2.2m的悬挑雨棚5个，1.2m*5.1m悬挑雨棚1个Si ngle layered color plate without in sulati on, same material and panel with exterior wall pan el. Besides, one 30m*10.75m(width*hanging length, the same below)tension rod type canopy in unioad area; five of 1m*2.2m hanging canopies and one 1.2m*5.1m hanging canopy in main workshop wall.女儿墙：双层板结构，外侧板材同外墙面板， 内侧板材质同外屋面板。
沿新建厂房一周的同坡女儿墙，高度为 400mm.Parapet: double layered color plate without insulation; exterior side has the same material with exterior wall panel and in terior side with exterior roof pan el. The parapet has the same slope with roof around new workshop buildi ng, with the height of 400mm.排水系统：drain age sys内天沟：上海美建标准的不锈钢内天沟Interior gutter: shanghai ABC 's standard stainless steel interior gutter.PVC 雨水管： PVC downspout 收边系统：包括山墙收边、檐口收边、门洞收边、屋脊收边等，材料为镀铝锌板Flashing and trim: for gable wall, eaves, roof ridges and wall openings. The material is aluminum-zinc alloy coated steel panel.附件系统： accessories自功螺钉： screws 密封胶：采用美国 Sika 公司生产的 Sika 系列密封胶带 sealant: Sika series sealing tape from Sika company 防热胀冷缩功能件及纵向搭接处的加强衬板。
Function devices to prevent deformation caused by temperature stress and strengthening scaleboard panels for longitudinal overlap.地角螺栓：包括垫块和抗剪件，材料为 Q235anchor bolts, including shims and anti-shear plate.Q235 strength 钢梁柱 beam and column底漆 priming (priming painting) 面漆 facial paint 收边、泛水板： trim and flashing 油漆及喷砂处理： painting and shot flashing 雨棚： canopy地脚螺栓： embeded bolts 抗渗漏金属屋面系统： leak-resistance metal roofing sys 抗剪刚度 shear stiffnessstiffness :劲度、刚度、强度ss360 roof stytem: s。
