万向A123动力电池产品和技术路线 Wanxiang A123 Battery Product and Technology Roadmap,浙江万向亿能动力电池有限公司 Wanxiang A123 Systems Asia CO., LTD April 11, 2014,,AVT波士顿 ESG波士顿,A123 常州,欧洲办公室,ASG 底特律,ATBS 上海,,万向亿能,常州材料基地,底特律基地,杭州基地,常州电池基地,万向A123全球业务分布 Wanxiang A123 Systems LLC Global Locations,2,000 employees in locations worldwide 1,000,000 square feet of manufacturing facilities in United States and China Global Headquarters, Livonia Michigan Global R&D Center, Boston, Ma Global Manufacturing Center, Hangzhou, China,万向A123产品技术构架 Wanxiang A123 Products and Applications,开发 Development 批量供货 Field Experience,车用动力电池的应用和客户 Transportation Customers & Applications,,,EV,PHEV,HEV,Micro-Hybrid,TBA 1,,,EV,PHEV,HEV,具有国际竞争力的电芯产品 High Performance Battery Cell Products,LFP Cell Product 磷酸铁锂产品系列： 高功率、长寿命、高安全性、能量功率兼顾 14Ah High Power 14Ah功率电芯， HEV 20Ah PHEV/SSB 20Ah 能量功率兼顾型 50Ah EV BUS 50Ah EV大巴用,NCM Cell Product 三元产品系列： 高能量、低成本、安全性、能量功率兼顾 20Ah NCM/LMO PHEV 功率型 157Wh/Kg 22Ah NCM EV 能量型 170Wh/Kg 38Ah NCM EV 能量型 170Wh/Kg,Proprietary Technology – EXT 专有技术：超温EXT技术、卷绕式叠片技术,目前该产品已经完成样品设计和产品认证，引入杭州工厂进行批量制造，订购了产业化的生产装备，预计2014年6月份具备量产的能力。
混合动力汽车动力电源 HEV Battery Application,杭州导入A123新电芯产品：HEV用8-14Ah A123 14Ah HEV Cell Introduced to Hangzhou,45度高温10C放电循环寿命,-25度低温脉冲放电- 200W,万向电池系统设计,,电芯,软包装电芯设计,电芯结构保护 绝缘保护,,多个子系统的集成 BMS和控制算法（SOC/SOH/SOF） 结构强度设计 热管理设计,,单元,,模块,集成热管理系统 标准模块化设计 高可靠性连接,,高性能电芯 集成化热管理 电压温度采集,子系统,,系统,电源系统整体解决方案 Battery System Solutions,LECU,BMU,EDM,电池系统解决方案的能力 Battery System Solutions and Capabilities,9,Pack Systems Integration Applications Engineering,Pack/Core Engineering Core SW/HW/BMS,Cell Core Module Module Applications Pack Mechanical Apps Application SW/HW,Pack Level EE ICD, System Integration Plan Battery Pack User Manual & Pack Functional Specification Compliance/Exceptions Document Electrical Engineering Block Level Diagrams Pack Level Mech. Eng. ICD Pack Level FMEA, DVP&R, and EOL Test Plan,,BMS Requirements Specification Systems Validation Plan HW/SW Interface Specification Software Requirements, Software Validation Plan, SPICE Compliance Documentation Hardware Requirements, Schematics, HW Validation Plan, Board Level EOL Test, Board Level FMEA, D&R Mechanical Design, D&R on all Mechanical,,,Mfg. Build Book/Prototype Control Plan Component Level Validation Verify Specification Compliance Update Component, HW, SW DFMEAs Manufacturing Process SW Driver Validation,,System Mechanical HW SW SW/HW Integration,电池系统开发流程导入 Battery System Engineering Process – V Model,10,,,2014 工作目标 (杭州工厂) 杭州电芯生产线建立 A123 AOS 和质量体系导入 MES系统建立和运行 通过OEM主机厂审核,,实施路线（从前至后） 系统需要在持续改善过程中不断完善,AOS 实施路线图,万向杭州工厂建立A123制造和质量体系 A123 Operation System Introduced to Hangzhou,,,手持条码扫描,信息交互界面HMI,现场质量信息录入,生产设备信息收集 (PLC),现场设备 Databases,万向杭州工厂建立A123制造执行和追溯系统(MES) A123 MES and Tracebility Introduction,100 scientists and engineers, 9000 square meter world class lab 100 名科学家，工程师，技师， 9,000 平方米世界级实验室,万向A123 波士顿电池基础研发中心 A123 Boston R&D Center,,,2012 2013 2014 2015 2016 2017 2018,100,200,300,Energy Density (Wh/Kg),万向A123 锂电池技术路线 Wanxiang A123 Li Battery Cell Roadmap,,,,,,,,,,,add 60Ah,,,w/IBS,w/IBS,modified,14,14,,add IBS,80Ah,低压电池系统解决方案 – 新产业应用 Low Voltage System Solutions – New Application,Thanks For Your Attention!,。
